آلة طلاء الألومنيوم
Created with Pixso. LKS300 Aluminum Foil Sheet Pop Out Machine V Z Shape Interlocking Baking Paper

LKS300 Aluminum Foil Sheet Pop Out Machine V Z Shape Interlocking Baking Paper

اسم العلامة التجارية: LIKEE
رقم الطراز: LKS300
الـ MOQ: 1 مجموعة
السعر: USD39,000-45,000
وقت التسليم: 1 شهر
شروط الدفع: T/T ، LC
معلومات مفصلة
مكان المنشأ:
شنغهاي ، الصين
إصدار الشهادات:
CE, ISO
نموذج:
LKS300
التجميع:
آلة ورقة رقائق الألومنيوم
طي الشكل:
شكل V/Z متشابك، زاوية طي 3-5 مم
لفة الأم المتاحة العرض:
max.610 و 910mm
كهربائي:
380V 50Hz 3 مرحلة + netural + الأرض
استهلاك الهواء:
0.5-0.8mpa
تثبيت الطاقة:
27 كيلو وات
إجمالي الوزن:
4000 كجم
كفاءة الإنتاج:
400-500 ورقة/دقيقة
الآلة الأبعاد الشاملة:
5000x2000x1700mm
سمك الرقائق:
0.010-0.020mm
القدرة على العرض:
1 مجموعة 1 شهر
إبراز:

aluminum foil pop out machine,V Z shape baking paper,interlocking aluminum foil sheets

,

V Z shape baking paper

,

interlocking aluminum foil sheets

وصف المنتج







LKS300 Aluminum Foil Sheet Pop Out Machine V Z Shape



Interlocking Baking Paper




Product Description:



LKS300 Aluminum Foil Sheet Pop-out Machine is mainly used for processing V/Z shape interlocking baking paper. It can automatically cut V-shape or Z-shape interlocking structures, and the cut baking paper is delivered via pop-out design, reducing manual intervention, suitable for batch production in baking packaging factories. Aiming at the structural characteristics of V/Z shape interlocking, the machine optimizes the cutting path to ensure accurate locking edges, no easy breakage, and uniform finished product size, which can match the packaging needs of baked foods (such as bread, cakes). Whether cutting V-shape alone or switching to Z-shape, the operation is simple, and it can quickly adapt to manufacturers' processing needs for different specifications of baking paper.


LKS300 Aluminum Foil Sheet Pop Out Machine V Z Shape Interlocking Baking Paper 0


Key Features:

  1.

  2. • Specialized V/Z shape interlocking design
    • Quick mold change system
    • Automatic counting and stacking
    • Custom molds available



Parameter Table:



Forming Type V/Z shape interlocking
Raw Material Aluminum Foil
Material Thickness 10-20micron
Mother Roll Core Diameter 76mm(3inch)
Max Mother Roll Diameter Max.800mm
Mother Roll Available Width Max.635mm&950mm



Sample Display:

LKS300 Aluminum Foil Sheet Pop Out Machine V Z Shape Interlocking Baking Paper 1LKS300 Aluminum Foil Sheet Pop Out Machine V Z Shape Interlocking Baking Paper 2LKS300 Aluminum Foil Sheet Pop Out Machine V Z Shape Interlocking Baking Paper 3LKS300 Aluminum Foil Sheet Pop Out Machine V Z Shape Interlocking Baking Paper 4

Product Q&A:



Q: What's the main feature of this machine?
A: Specifically produces V and Z shape interlocking baking paper for secure packaging.

Q: Will the interlocking structure after cutting break easily?

A: The cutting path has been optimized, the locking edge part is cut stably, and it is not easy to break.

Q: How thick V/Z shape baking paper can the machine cut?

A: It is compatible with the thickness of conventional food-grade baking paper, and the specific can be confirmed according to the actual material.

Q: What's the production speed?
A: Adjustable speed, up to 400-500 pcs per minute.

Q: Will the pop-out sheet delivery cause paper jams?

A: The sheet delivery structure is adapted to the characteristics of baking paper, and it is not easy to jam under normal use.
